Below are the functions and provided info from IRIS plus.
Angle measurement ON/OFF, selection is stored to the given bend step. It might be
necessary to turn measurement OFF in some cases where IRIS plus system won’t be able to
measure the angle reliably, like for example too short ange.
If bent angle is incorrect after the measurement cycle, bend step can be repeated by turning
this o and adjusting angle correction manually.
When bending open prole (not a box, Lazersafe tray mode is OFF) nal angle will be
conrmed precisely by closing the press with crawl speed until target angle is reached.
When bending box/closed prole tray mode must be turned ON. In tray mode nal bottom
dead point will be calculated according measured and adjusted angle correction and spring
back.
With above button operator can choose if the spring back will be measured or not. Measured
spring back is stored to a given bend step, and it is possible to turn spring back measurement
o after the rst part to fasten the cycle. Note that if stored spring back value is zero, spring
back will be measured at least once.
Angle correction. When measurement is ON, system adjusts this value automatically, towards
to the programmed target angle. Spring back is added besides this when dening the actual
bottom dead point of the bend step.
If this value is 0, basically when new program has been created, angle is rst left open
intentionally by several degrees to avoid part being over bend.
If a die, material thickness or programmed angle will be changed to an existing program this
value will be reset to 0 to avoid over bend.
If angle correction is 0 and measurement quality drops to 0% during cycle angle correction
will be 0.1 and normal bend cycle without measurement will be executed.
