Autonics BEN Series Product Manual

■ Dimensions
(Unit: mm)
MS-2□ MS-3□
2-Ø3.8
40.5
34
8.5
2.5
3.25
60.5
52
4.2
34 40.8
3.4
52
60.5
81.5
4-Ø3.840.83.4
2.5
8.5
MS-4
2-Ø3.2
20
29.3
2
7.5
2.8
38
MS-5 MS-6
9.5
2
11.4
15.4
2-Ø2.2
20.4
24
2
1.4
4.813.7
9.7
19
23
2
2
4
4
2-Ø2.2
■ Cautions during Installation
•
environment of the sensors.
•
•
•
Appearance Size (W × H) Sensing type Model
40.5 × 60.5 mm
Typical
reflectivity
MS-2
Typical
reflectivity
Polarized
MS-2A
High
reflectivity
Polarized
MS-2S
81.5 × 60.5 mm
Typical
reflectivity
MS-3
High
reflectivity
Polarized
MS-3S
29.3 × 38 mm
Typical
reflectivity
MS-4
15.4 × 24 mm
Typical
reflectivity
MS-5
13.7 × 23 mm
Typical
reflectivity
MS-6
• Material: PMMA / ABS (front part / rear part)
• Installation: Bolt mounting
■ ■ Bracket
6
6 6
Output method AC/DC power, relay conctact output DC power, solid state (transistor) output
Power supply
24-240 VACᜠ ± 10 % 50/60 Hz
24-240 VDCᜡ ± 10 %
(ripple P-P: ≤ 10 %)
12-24 VDCᜡ ± 10 %
(ripple P-P: ≤ 10 %)
Power / current
consumption
≤ 4 VA It depends on the sensing type
Through-beam - Emitter: ≤ 50 mA, receiver: ≤ 50 mA
- ≤ 50 mA
Control output Relay contact output
NPN open collector - PNP open
collector simultaneous output
Contact capacity
250 VACᜠ 3 A of resistance load,
30 VDCᜡ 3 A of resistance load
-Conctact composition 1c
Relay life cycle
Mechanical: ≥ 50,000,000
Electrical: ≥ 100,000
Load voltage
-
≤ 30 VDCᜡ
Load current ≤ 200 mA
Residual voltage NPN: ≤ 1 VDCᜡ, PNP: ≤ 2.5 VDCᜡ
Protection circuit -
Reverse power protection circuit,
output short overcurrent protection
circuit
Insulation
resistance
≥ 20 MΩ (500 VDCᜡ megger)
Insulation type
Double or strong insulation (dielectric
voltage between the measured input
and the power : 1 kV)
-
Noise immunity
± 1,000 VDCᜡ the square wave noise
(pulse width: 1 ㎲) by the noise
simulator
±240 VDCᜡ the square wave noise
(pulse width: 1 ㎲) by the noise
simulator
Dielectric strength
Vibration
1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z
direction for 2 hours
Vibration
(malfunction)
1.5 mm double amplitude at frequency
of 10 to 55 Hz in each X, Y, Z
direction for 10 min
-
Shock 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times
Shock
(malfunction)
100 m/s² (≈ 10 G) in each X, Y, Z
direction for 3 times
-
Ambient
illuminance
(rec
eiver)
Sunlight: ≤ 11,000 lx, incandescent lamp: ≤ 3,000 lx
Ambient
temperature
-20 to 65 ℃, storage: -20 to 70 ℃ (no freezing or condensation)
Ambient humidity 35 to 85 %RH, storage: 35 to 85 %RH (no freezing or condensation)
Protection rating IP54 (IEC standard)
Connection Cable type
Cable spec.
Wire spec. AWG22 (0.08 mm, 60-core), insulator outer diameter: Ø 1.25 mm
Material
Case and case cover: heatresistant ABS, sensing part: PC (polarized
Model BEN10M-T▭ BEN5M-M▭ BEN3M-P▭ BEN300-D▭
Sensing type Through-beam
Polarized
Sensing distance 10 m 0.1 to 5 m
01)
0.1 to 3 m
01)
300 mm
02)
Sensing target Opaque materials Opaque materials Opaque materials
Opaque,
translucent
materials
Min. sensing target ≥ Ø 16 mm ≥ Ø 60 mm ≥ Ø 60 mm -
Hysteresis - - -
≤ 20 % of sensing
distance
Response time
AC/DC power, relay contace output model: ≤ 20 ms
DC power, solid state (transistor) output model: ≤ 1 ms
Light source Infrared Infrared Red Infrared
Peak emission
wavelength
850 nm 940 nm 660 nm 940 nm
Sensitivity
adjustment
- YES (Adjuster) YES (Adjuster) YES (Adjuster)
Operation mode Light ON mode - Dark ON mode selectable (Adjuster)
Indicator Operation indicator (red), stability indicator (green), power indicator (red)
03)
Unit weight
(AC/DC power)
≈ 354 g ≈ 208 g ≈ 208 g ≈ 195 g
Unit weight
(DC power)
≈ 342 g ≈ 200 g ≈ 200 g ≈ 187 g
01)
02) Non-glossy white paper 100 × 100 mm
03) Only for the emitter
Approval
IP50 (IEC standard)
Ø6mm, 5-wire, 2m(Emitter of through Ø5mm, 4-wire, 2m(Emitter of through
-beam type: Ø5mm, 2-wire, 2m) -beam type: Ø5mm, 2-wire, 2m)

Autonics BEN Series Specifications

General
