나 1 Product Overview
© Copyright Reserved Autonics Co., Ltd. 15
① Counting value display component (red)
RUN mode: Displays counting value for counter operation or time progress value for timer
operation.
Setting mode: Displays parameter.
② Setting value display component (green)
RUN mode: Displays setting value.
Setting mode: Displays parameter setting value.
③ Key lock indicator (LOCK): Turns ON for key lock setting.
④ Counter indicator (CNT): Turns ON for counter operation.
⑤ Timer indicator (TMR): Flashes (progressing time) or Turns ON (stoping time) for timer
operation.
⑥ Setting value checking and changing indicator (PRESET1, PRESET2)
: Turns ON when checking and changing setting value.
⑦ Output indicator (OUT1, OUT2): Turns ON for the dedicated control output ON.
⑧ key
RUN mode: Press the key to reset the counting value.
BATCH counter mode (CTM Series)
: Press the
key to reset the batch counting value.
⑨ key
RUN mode: Enters parameter setting mode or communication setting mode.
Setting mode: Saves setting value and return to RUN mode.
⑩
, ,
- key
RUN mode: Enters setting value change mode.
Setting value change mode: Moves setting value digits.
- key
Setting value change mode, Setting mode: Changes setting value.
Setting value check mode: Checks setting value of the previous parameter.
- key
RUN mode: Enters setting value check mode.
Setting value change mode, Setting mode: Changes setting value.
Setting value check mode: Check setting value of the next parameter.
⑪ key
RUN mode: Enters BATCH counter indication mode.
⑫ BATCH output indicator (BA.O) (red)
: Turns ON when BATCH output is ON.
⑬ BATCH setting value checking and changing indicator (BA.S) (green)
: Turns ON when checking or changing BATCH setting value.
CT4S-1P
PRESET2 → PRESET
OUT2 → OUT
No PRESET1, OUT1 LEDs
CT6S-1P
CT6Y-1P
CT6M-1P
CT6S-I
PRESET2 → PRESET
No PRESET1, OUT1, OUT2 LEDs
CT6Y-I
No PRESET1, OUT1, OUT2, BA.S, BA.O LEDs.
No key.
CT6M-I
※ CT4S model does not support indicator type.
