4) The maximum operating pressure of standard hose is 600 PSI
( approximate 4.13 Mpa, 41.3 bar ). The limit pressure is 3000 PSI
approximate 20.68 Mpa, 206.8 bar ).
5) Please confirm the rated pressure value of the tested equipment before
testing. Do not use it if it exceeds the range of the instrument. If the packed
hoses does not match the pressure requirement, you can use suitable
replacements for testing.
6) Do not use and store the instrument in high temperature, high humidity,
flammable, explosive and strong electromagnetic fields.
7) Please do not change the instrument internal circuit, to avoid any
damage of the instrument or danger occurring.
8) Please wear qualified protective equipment to protect user during testing.
Please use the instrument in a well-ventilated environment to prevent
inhalation of toxic gases.
3.International electrical symbols
4.Product specifications
Pressure test: gauge pressure
Pressure test unit: Kpa; Mpa; bar; inHg; PSI. Pressure test range: 0 Kpa –
6000 Kpa Pressure test resolution: 1 Kpa
Pressure test accuracy: +/- 0.5 %(FS)+ 5dgt
Pressure overload limit: 10000 Kpa (10 Mpa; 100 bar;)
DC
AC
DC/AC
warning
dangerous voltage(electric shock)
earth
double insulation
fuse
battery
