Autotrol Duplex - Programming Details and Operating Data

10
Vessel Size 835 935 1035 1044 1054 1248 1354
Media Volume (each vessel) 20 25 30 40 50 60 75
Valve Type 255 255 255 255 255 255 255
Parameters
Time of day (HH:MM) P1
Day of week P2
Time of regeneration (HH:MM) P3
Calendar overide days P4
Salt ammount (gms) P6
Capacity (Kg) P7 1 1.2 1.5 2 2.5 3 3.8
Hardness (ppm) P8
Refill rate (gpm x 100) P14 33 33 33 33 33 33 33
Brine draw rate (gpm x 100) P15 18 18 22 26 26 38 50
Vessel Size 1354 1465 1665 1865 2160
Media Volume (each vessel) 75 100 125 200 250
Valve Type 278 278 278 278 278
Parameters
Time of day (HH:MM) P1
Day of week P2
Time of regeneration (HH:MM) P3
Calendar overide days P4
Salt ammount (gms) P6
Capacity (Kg) P7 3.8 5 6.2 8.8 11.2
Hardness (ppm) P8
Refill rate (gpm x 100) P14 130 130 130 130 130
Brine draw rate (gpm x 100) P15 56 56 67 84 84
Vessel Size 1665 1865 2160 2469 3072 3672
Media Volume (each vessel) 150 200 250 350 500 700
Valve Type 298 298 298 298 298 298
Parameters
Time of day (HH:MM) P1
Day of week P2
Time of regeneration (HH:MM) P3
Calendar overide days P4
Salt ammount (gms) P6
Capacity (Kg) P7 6.2 8.8 11.2 15 25 35
Hardness (ppm) P8
Refill rate (gpm x 100) P14 80 140 140 200 300 500
Brine draw rate (gpm x 100) P15 50 90 90 140 200 300
Set on site / factory default 2,00am
Set on site / factory default 14 days
150
Set on site
Set on site / factory default 14 days
150
Set on site
Set on site
Set on site
Set on site / factory default 14 days
150
Small Commercial Softeners
Set on site
Set on site
Set on site
Set on site
Set on site
Set on site / factory default 2,00am
Larger Commercial Softeners
Set on site / factory default 2,00am
5.2 Programming Details and Operating Data.
