Autotrol Magnum Cv 962 - Dimensional Specifications

8
2.3 Magnum Cv Dimensional Specifications
1 1/2-inch Inlet, Outlet and Drain
3.993 (10.14 cm)
6.493 (16.5 cm)
7.500 (19.05 cm)
22.796 (57.90 cm)
2.817 (7.15 cm)
4.018 (10.20 cm)
8.680 (22.04 cm)
9.000 (22.86 cm)
13.481 (34.24 cm)
19.500 (49.53 cm)
7.000 (17.78 cm)
14.000 (35.56 cm)
15.539 (39.47 cm)
1.113 (2.82 cm)
11.471 (29.13 cm)
