- 2 -
Dimensions
(1) Indoor unit
MODEL
DIM
7K BTU Series 9K,12K BTU Series 18K,24K BTU Series
W mm 680 745 1095
H mm 250 250 312
D mm 180 210 205
(2) Outdoor unit
MODEL
DIM
7K BTU Series 9K,12K BTU Series 18K BTU Series 18K,24K BTU Series
W mm 600 760 800 800
H mm 490 540 590 690
D mm 250 260 300 300
