22
EXAMPLE 2:
1. To program zone 4 as 24H zone (in default program, this is an Instant Zone).
2. Address 024 represents the 24H zones
3. Press
0
Shunt
2
Shunt
Display
4
Delay
Delete
; current value of the address is ‘-’ (‘-’ means blank - no 24H zone is
programmed). Three LEDs will blink and an ‘-’ will be displayed (default program).
4. To enter new required value press the address number
0
Shunt
2
Shunt
Display
4
Delay
Delete
then enter new
value ‘8,’ by pressing
4
Delay
Delete
(zone 4).
‘U’ confirms programming updating.
5. ‘P’ is displayed; two left-most LEDs are blinking.
Note: To delete a programmed feature, enter ‘0’ at feature’s address
EXAMPLE 3:
1. To program zone 1 to 4 as “Fast Response Zone”.
2. Address 032 represents “Fast Response Zone”.
3. Press
0
Shunt
3
Status
2
Shunt
Display
; current value of the address is blank;
three LEDs will blink and ‘-’ will be displayed (- means blank; no Fast Response Zone is default
program).
4. To Enter new required value press the address number
0
Shunt
3
Status
2
Shunt
Display
then enter new
value 1 2 3 4 by pressing
1
Siren
2
Shunt
Display
3
Status
4
Delay
Delete
.
‘U’ confirms programming updating.
5. ‘P’ is displayed, two left-most LEDs are blinking.
19. RESET SYSTEM TO DEFAULT PROGRAMMING
Warning!
This function erases all codes and system programming settings.
1. Enter program mode.
2. Go to address 200 and enter ‘6’ and ‘9’. Display will show
E P R
, and system will revert to
factory default program. Code No. 1 is 1 2 3 4; programming code will be 1 9 9 4.
Quitting and Updating new Programming via AV-701 Keypad
Upon programming completion, hold down key
9
Reset
.
Wait for a long beep, and then release the key.
When ‘P’ is no longer displayed, the system has reverted to Disarmed mode.
Note:
The system disregards erroneous or conflicting programming features upon quitting
program mode. For example: Programming the same zone as 24H type and delayed zone,
considered as 24H zone.
Reset System to Default Codes
This feature is enabled by default, to disable remove the 8 in address 072.
By holding-down keys
*
#
Keypad Panic
during power-on (by applying AC and Battery), after
2
nd
beep release keys, ‘U’ will be display 3 times in confirmation.
User code No. 1 (1234) and programming code (1994) will reset to default.
