AV-GAD EasyLoader AV-2004 - Page 27

27
Addendum: Technical Specifications AV-2004 and AV-2048
Operating Temperature
-10

C to 60

C
Relative Humidity
80% maximum
Input AC Power
16V AC Step-Down Transformer 1.2A
Dynamic Inner Memory
EEprom
Auxiliary Power Output
13.8 Volts +/- 5%, Regulated
Short & Overload circuit protection
Siren Output
Siren or Bell Selectable
Bell Mode: 13.6V DC - 0.5A
Siren: 8 Ohms, 15W
Dialer: Programmable 3 telephone numbers
& 1 Follow Me telephone number (4 phone
numbers).
Multi-format central-station communicator
Pulse Dialing parameters programmable
DTMF: Touch Tone dialing

Max. Telephone number length: 16 digits
and 4 pauses.
Remote Indications on Wire Terminal
Open Collector type output
200mA Max. @ 12V DC
Zone Loop Voltage
12V VDC or 6V with EOL resistor
Zone Loop Current
5 mA with End-Of-Line Resistor
Zone Maximum Wire Length
200 meters with
0.5-mm
2
wires
EOL Zone Loop Resistor
2,200 Ohms, 0.25W, +/- 5%
AV-2048
: 2,200 and 4,700 Ohms
Auxiliary Power (Max.)
13.6V DC 0.5A Combined AUX Power
and Keypad outputs.
Battery Charging Current (Max.)
550 mA, current limited
Battery Test: Indication at keypad or remote
indication via communicator
Performed at 0.5A load for 1 second.
Low Battery indication below 9.5V
Tested upon Arming and every 60 minutes
during Armed and Disarmed
Standby Power Consumption at Disarmed
mode, and Keypad display is Off
90 mA, +/- 10 %
Maximum Remote Station (Keypads)
Three Keypads AV-701T or AV-701TI
Five Keypads AV-702
Remote Station Current Consumption
AV-701T: 27mA. AV-701TI: 36mA
Housing Dimensions
(H) 30, (D) 9, (W) 23 cm
System Housing
Standard: ABS plastic box
Option: Anodized, lockable metal box
Epoxy anti-static powder painted
Gross Shipping Weight
0.9 kg (ABS box, without transformer). 6
PCs per master box
Fuses: Electronic Fuse
Auxiliary Power: 1.2A
Sirens: 1.2A
Backup Battery Fuse: 2.5A
This product is subject to continual enhancement and therefore
specifications may be changed or altered without prior notice
