When a non-blinking ‘8’ is displayed and keys do not respond, it is an indication that the
keypad is not communicating with the panel. Check wiring and polarity
Wire length for each AV-701 Keypad should not exceed 100 meters (when using 0.5 mm
2
wires).
For longer than 100 meter keypad wiring, contact manufacturer's consultant. For AV-701TIP
(with tamper) run five (5) wires. Connect the TMP terminal to a 24H or Tamper zone.
Power at Keypad should be a minimum of 11.5 Volts.
IMPORTANT! Never run Keypad wires alongside telephone wires, high voltage wires, or
transmitting antennae. Wire the keypad wires separately and not in same cable with other
devices (telephone, PIR etc.)
For proper connection, refer to wiring diagrams at the end of the manual.
4. SIRENS
The control unit contains single siren outputs, protected by Electronic Fuse.
Siren should be of an outdoor type with a minimum power of 15W, 8 Ohms Impedance.
Enclose the siren in a metal housing, with anti-tamper switch protection.
Siren mode is factory default, in Siren mode install only speaker-type sirens, which DO NOT
contain sound driver or electronic modules.
The alarm issued by the siren differs according to the type of zone.
‘Bell Mode’ converts Siren outputs into 13.6V DC outputs (no sound is issued). Bell mode
is applicable for driving self-powered sirens or bells, or combined sirens and strobes.
13.6V DC is issued at Bell mode. It’s recommended to use Bella sirens series.
In Bell mode, connect
only
sirens, which contain sound driver or electronic modules.
Self contain Bell mode is programmable (address 072-1 and 073-3). This mode provides
connection of Bells or Sirens that requires 13.6V at idle and 0V during alarm.
Contact manufacturer's consultant before connecting higher power loads.
To connect self-contained sirens, Bells, and inner-oscillating sirens, Bella siren series refer to
address 072-1 for Bell mode. Bella sirens support internal battery charge and monitor for
higher security.
Warning, Output current for Bell should not exceed 1.0 Ampere
5. AV-2004/48 Remote Indication Terminals
Indication Application
ON (-V) on closing (Arming) or if cross-zoning feature selected
A1 (-V) during alarm from the programmed zone
