Quad • Mounting guide | 11
In-ceiling mount
4 5
Put the bracket assembly in the correct position in the ceiling and install the tile.
Assemble the camera top mounting plate to the adapter plate, adjust the position so the camera
will be lush to the ceiling and the release button can be pressed.
Fasten the remaining two nuts to secure position of the rod.
Required:
ACQ-REC-KIT Recessed kit
