Avady ChloriProtect Rx - 8 Spare Parts List

Instructions and user manual ChloriProtect NOT004ENV05
AVADY POOL - 9, Chaussée Jules César, Bâtiment 4 Hall 406 - 95520 OSNY - France
Tél : +33 (0)1 34 48 16 03 Fax : +33 (0)1 78 76 73 95 Mail : contact@avadypool.com Site : www.avadypool.com
Installation and operating instructions are included with the product when purchased new.
8.0 SPARE PARTS LIST
Fig. 12
Code
Description of parts
1
AYAC100167
Bracket
2
AYAC100021
BNC
3
AYAC100161
Auxiliary plug C13
4
AYAC100164C
Circuit board ChloriProtect
5
AYAC08BC05
Rx Gold electrode
6
AYAC09CF07
Probe holder
7
AYFA00003
Shutter
8
AYAC100007
Clamp DN50
9
AYAC02C004
Buffer solution 475mV
NOT PROVIDED
AYACSOLSTOCK
Storage liquid for probe pH-RX 100mL
NOT PROVIDED
AYACSOLNET01
Cleaning solution for probe pH-RX 250mL
7
9
8
6
5
