4.3 Unit installation
STEP 1: Installation of the fixing bracket
Fig. 4
STEP 2: Prepare the sensor for startup
STEP 3 : Drill a hole in the pipe using tool F
Place the bracket on the area it should be fixed to
Mark the holes and drill to the diameter indicated on the
plugs
Secure the bracket
Slide the pump into the bracket
1) Remove the
sensor's protective
cap and keep it to re-
use it for the winter
shutdown period
2) Leave the sensor submerged in
tap water for at least 20 minutes,
before proceeding with the
calibration.
We therefore recommend that
you start your installation with
this step.
POOLeasy pH + POOLeasy RX
