6. Clean each water nozzle on the spray bar with a brush or sponge and the solution. Remove all
buildup in each nozzle opening to assure proper water flow. The spray bar may be removed to
facilitate cleaning. If necessary, vinegar may be used to help remove mineral build-up from the
water nozzles.
7. Remove the drain plug inside the water reservoir and clean it. Removing the plug will drain
the water reservoir so it can be cleaned as well. Rinse all surfaces. Make sure the drain plug is
reassembled in the correct position after cleaning or the water reservoir will not fill to make ice.
8. Using the sponge and brush, clean the corners, sides, and bottom of the ice bin with the cleaning
solution.
9. Remove the filter screens from the water reservoir and the ice bin. The ice bin filter screen consists
of two parts: A bottom and top. Move the drain hose slightly to access the ice bin filter screen.
Clean the filter screens in the solution and rinse under running water. Replace all filter screens and
return the drain hose to its position over the ice bin filter.
10. Poor an appropriate amount of cleaning solution down the ice bin drain. Rinse the inside of the bin
with clean water and allow it to drain.
11. Reassemble all remaining interior parts, reconnect power, and turn on the water supply. Turn power
switch to “ICE” and allow the unit produce a batch of ice. Discard the first batch. The ice maker is
now ready for use.
Ice Bin Filter Top
Ice Bin Filter Bo�om
