Specifications 5
Travis Industries 4011009 93508126
Heating Specifications:
Approximate Maximum Heating Capacity (in square feet)*.................................800 to 2,250 Sq. Feet
Burn Rate (Pounds per Hour)**.......................................................................1.7 to 5.5
Maximum Burn Time on Low Burn** ................................................................67.5 Hours
Hopper Capacity............................................................................................115 Pounds
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the fuel size, quality, and moisture level.
** Small pellets will increase or decrease the stated burn rates and burn times. Differences of plus or minus 20%
depending on fuel quality may occur.
Dimensions:
Weight: 250 Lbs.
Air Inlet
(1-3/4"
Outside
Diameter)
4"
Diameter
Exhaust
10-1/2”
17-5/8"
1/2"
7-1/4"
Center
Line
33-3/8"
26-1/2"
28"
This keyhole is for
the door handle.
This tab is for
the scraper
rod tool.
Electrical Specifications:
Electrical Rating.......................................................................................115 Volts, 3.6 Amps, 60 Hz
Watts During Start-Up Sequence..............................................................400 (approximately)
Watts During Operation............................................................................180 (approximately)
Fuel:
The unit is designed for wood pellets that comply with the standards set by the Association of Pellet
Fuel Industry (density of at least 40 lbs. per cubic foot, 1/4" to 5/16" diameter, length no greater than
1–1/2", 8200 BTU's/lb., moisture under 8% by weight, ash under 1% by weight, and salt under 300
parts per million). If the fuel does not comply to this standard, the unit may not operate as designed.
EPA Compliance:
This heater has been tested exempt from EPA Phase II Requirements by OMNI Test Labs.
