28 (40)
6.6 Transport position
When driving with the loader, keep the flail mower
lifted off the ground and tilted back slightly, as shown
in adjacent figure.
Keep the top link unlocked or locked to extended
position (see page 27 for top link locking).
Risk of tipping over - Keep the loader stable.
Always transport the attachment as low
and close to the ground as possible. Keep the telescopic boom retracted during
transport drive.
6.7 Adjusting cutting height
The cutting height of the flail mower can
be adjusted by changing the settings of
the roller and the skids, highlighted in the
adjacent figure.
Loosen the nuts with a single 24 mm
tool
Do not fully remove the nut -
loosen only enough to move the
bolt so that the height can be
adjusted.
Ensure the stability of the flail mower
during adjustments; use blocks of
wood for example. The mower
should be kept attached to loader for
performing the adjustments.
Set all fasteners to the same level.
6.8 Working on uneven ground
Extra caution is needed when using the equipment on inclined terrains and slopes. Drive slowly especially on
inclined, uneven, or slippery surfaces, and avoid sudden changes in speed or direction. Operate the controls
of the loader with careful and smooth movements. Watch out for ditches, holes on the ground, and other
obstacles, as hitting an obstacle may cause the loader to tip over.
Maximum lifting capacity can not be achieved on inclined terrain. On horizontally tilted terrain the load must
not be lifted high. The loader frame articulation should be kept straight when lifting heavy loads; turning the
load during lifting operation will affect the stability of the loader and may lead to overturning of the machine.
If it is necessary to use the Flail mower on inclined surface, ditches for example, it is recommended to use the
attachment with Avant Side shift adapter or Side shift arm.
