6.10 Blade options
As standard, the flail mower is equipped with hammer type blades, which give good all-round performance. In
some operating areas or conditions different blade types can be used. Contact your Avant dealer for new
blades.
Blades
Blade type Purpose Installation Number of blades
Flail mower
1200/1350/1500
Hammer type
blade
(standard)
65423
performance
Good for shrub and
brushwoods
16 / 18 / 20 pcs
Pair of Y-flails
A419931
cutting
16 / 18 / 20 pairs
Pair of L-flails
A420305
Good cut finish for short
grass areas
16 / 18 / 20 pairs
Note: Always fit the spacers shown in figures above when using Y- or L-flails.
When replacing blades, also the fastening bolt and the locking nut must be replaced (M14*80 bolt with
nyloc nut).
Use only locking nuts for fastening of the blades
Check if replacement of the spacers of the Y- and L-flail is necessary
