8 Control Layout
Rev C
Control Layout
AvantaPure Controller
LBS
PM
MIN
KG
x100
LCD Display
Manual Regen Button
Down Button
Set Button
Up Button
For Future Use
Turbine Input or Dry Contact Signal Input
Main Motor &
Optical Sensor
Connection
AC Adapter
(low voltage)
Input
Chlorine Generator Outlet
