PARTS LIST
Item Item# Part # Description
1 DWS1-010001 Body Assembly
DWS2-010001 Body Assembly
DWS3-010001 Body Assembly
2 DWS-010321 Element Bracket
3 423WDNP3 DWFRGS-120 Heating Element
4 DW-030001 Pan
5 DWS-020301 Center Pan Support Assembly
6 DWS-020201 Drawer Face Assembly
7 423WDNP7 DWS-020401 Drawer Handle
8 423WDP8 N/S Drawer Vent Knob
9 423WDNP9 DWS-020701 Gasket
10 DWS-020101 Drawer Inner Frame Weldment
11 423WDP11 DW-020501 Guard Bearing
12 423WDP12 DW-020601 Slide Bearing
14 423WDP14 N/S Thermostat 250V 105°
15 423WDP15 N/S Knob
16 423WDP16 N/S Mechanical Temperature Indicator(0~120°)
17 N/S Power Indicator Light
18 N/S Control Panel 1 Drawer
N/S Control Panel 2 Drawer
N/S Control Panel 3 Drawer
19 423WDP19 N/S Cord & Plug NEMA (5-15)
20 N/S Cable Bushing
21 423WDP21 N/S Leg
21B 423WDNTK3 DWSB3-010201 Trim Kit (Convert Free-standing to Built-in model)
22 423WDP22 N/S Caster with Brake (Option)
23 423WDCASTER N/S Caster (Option)
24 N/S Screw 1/4-20X1.25"
25 N/S Screw 1/4-20X0.75"
26 N/S Nylon Lock Nut 1/4-20"
NOTE: Casters and trim kits are accessory options that do not come with free-standing units unless otherwise noted.
