3
Contents
Safety Rules 4
Tool Specifications 5
Intent of Use 6
Tool Dimensions 6
Putting into Service
Air Supply 7
Stroke Adjustment 7
Operating Procedure 7
Nose Assemblies
Fitting & Servicing Instructions 8
Selection 9
Servicing the Tool
Daily / Weekly 10
Molykote 55M Safety Data 10
Service Kit 11
Maintenance
Pneumatic Cylinder 12
Rod Guide 12
Trigger 12
Swivel Air Inlet 12
Differential Valve 13
Head Assembly 13
Rear Casing 13
Distributor 13
Hydraulic Piston & Air Motor Assembly 13
General Assembly of Base Tool
General Assembly and Parts List 14-15
Priming
Oil Details & Safety Data 16
Priming Procedure 16
Fault Diagnosis
Symptom, Possible Cause & Remedy 17-18
LIMITED WARRANTY
Avdel makes the limited warranty that its products will be free of defects in workmanship and materials
which occur under normal operating conditions. This Limited Warranty is contingent upon: (1) the product
being installed, maintained and operated in accordance with product literature and instructions, and (2)
confirmation by Avdel of such defect, upon inspection and testing. Avdel makes the foregoing limited
warranty for a period of twelve (12) months following Avdel’s delivery of the product to the direct purchaser
from Avdel. In the event of any breach of the foregoing warranty, the sole remedy shall be to return the
defective Goods for replacement or refund for the purchase price at Avdel’s option. THE FOREGOING
EXPRESS LIMITED WARRANTY AND REMEDY ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES
AND REMEDIES. ANY IMPLIED WARRANTY AS TO QUALITY, FITNESS FOR PURPOSE, OR MERCHANTABILITY
ARE HEREBY SPECIFICALLY DISCLAIMED AND EXCLUDED BY AVDEL.
Avdel UK Limited policy is one of continuous product development and improvement and we reserve the right to change the specification of any product without prior notice.
