Avdel 74200 - Intent of Use; Tool Dimensions

6
Intent of Use
The hydro-pneumatic 74200 tool is designed to place Avdel
®
threaded inserts at high speed making it ideal for batch or flow-line assembly in a
wide variety of applications throughout all industries.
A complete tool is made up of the base tool (part number 74200-12000) and the appropriate nose assembly for the insert, as
described on page 9.
NOSE ASSEMBLIES MUST BE FITTED AS DESCRIBED ON PAGE 8.
115Ø
4.53Ø
280
11.02
63
2.48
9.84
250
63Ø
2.48Ø
27Ø
1.06Ø
Dimensions shown in bold are millimetres. Other dimensions are in inches.
Tool Dimensions
