AVer M11-8M User Manual

4
Device Connection
Power Connection to Wall Outlet
Plug in power and turn on M11-8M.
Wall Outlet
USB Power adapter
(Not included)
USB cable

[Note]
 Use the USB cable which included in package connects to mini
USB/ Power port of M11-8M with USB power adapter (not
included)to wall outlet.
 User needs to purchase a 5V/1A USB power adapter (not included)
to connect the USB cable to wall outlet.
 When the camera is start-up, the power indicator is in flashing red.
1

AVer M11-8M Specifications

General

Sensor type	CMOS
Image freeze	Yes
White balance	Auto, Manual
Maximum frame rate	60 fps
Optical sensor size	1/3.06 \
Maximum video resolution	1920 x 1080 pixels
Effective sensor resolution	8 MP
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Digital zoom	20 x
Maximum aperture number	2
Operating current	0.9 A
Operating voltage	5 V
Power supply type	USB
Interface	USB 2.0
USB connector type	Mini-USB A, USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
HDMI output ports quantity	1
Mac operating systems supported	Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Quantity per pack	1 pc(s)
Product color	Black
Document size (max)	A3
Image quality adjustment	Brightness, Contrast, Mirror, Saturation
Horizontal rotation angle	0 - 180 °

Weight and Dimensions

Depth	303.4 mm
Width	116.7 mm
Height	360.4 mm
Weight	830 g
Dimensions folded (WxDxH)	116.7 x 143.1 x 296.1 mm
