12 of 48
Bottom View
1. Ventilation slots
2. RAM compartment
3. Battery release button
4. Battery pack
1
2
3
4
LED Status Indicators
The status indicators in the upper left corner of the keyboard light up when a particular function of the
computer is active. Each indicator is marked with a symbol.
Optical Drive
The computer is reading information from the
optical drive.
HDD
The computer is reading from, or writing to the
built-in hard disk.
Number-Lock
The keyboard is in Num-Lock mode.
Caps-Lock
The keyboard is in Caps-Lock mode.
Scroll-Lock
The keyboard is in Scroll-Lock mode.
