IMPORTANT
• Arectangularductof 3¼’’x10‘’oraroundductofaminimumof6”(standardforthisrangehood)must
beusedtomaintainmaximumairflowefficiency.
• Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting toduct
provided.



VENTING METHODS
INSTALLATIONDIAGRAMS
• Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow may be
needed
.
• This range hood is factory set for vertical venting using round or rectangular vent adapter but can be
convertedtohorizontalventingbyswapping theroundventadapterontopwith rectangularventadapter
behindtherangehoodasshownbelow
:
Option1:
Horizontalventing
Option2:
Verticalventing
Roofcap
Wallcap
25
Type 1:
3¼’’x10’’rectangularventadapter
behindtherangehood.
Type 2:
3¼’’x10’’rectangularventadapter
ontopoftherangehood.
Type 3:
6’’roundventadapteronthetopof
therangehood.
