AVG BOSTON - Cabinet Cut-Out Dimensions



Model/AVB306RS

CABINETCUT‐OUT(seenfromthetop)



27
CABINETCUT‐OUT(seenfromtherear)
Woodfillersupport
strips
(notincluded)
ElectricalAccess‐opening
Mountin
g
scre
w
attachmen
t
WALL
Topduct
/exhaust
access
ElectricalAccess‐
Opening
centerline
Mountingscrews
Rearductaccess
centerline
