1.2.3

Install the lock nut onto the leveling foot and thread the leveling foot into the foot plate.

M12 Hex Nut

7038 M12 Leveling Foot

Benchtop PRO

Assembly Instructions

Version 2020Q2.1

© 2020 Avid CNC

All Rights Reserved
