5 Specifications and Notices
This section provides information on the physical and electrical specifications for the Avid NEXIS
Engines and the optional external System Director. Avid recommends the use of an Uninterruptible
Power Supply (UPS) and supported network cabling.
Physical
Electrical and Power
UPS systems must specify a transfer time of <10ms in order to prevent power loss to the power
supply modules. The power supply modules for an Engine should not be connected to the same UPS.
Component Width Depth Height Weight
System Director Appliance 483 mm (19 in) 630 mm (24.8 in) 88.9 mm (3.5 in) 16.7 kg (37 lb)
Avid NEXIS | E2,
Avid NEXIS | E2 SSD,
Avid NEXIS | PRO
483 mm (19 in) 630 mm (24.8 in) 88.9 mm (3.5 in) 26 kg (57.2 lb) with drives
Avid NEXIS | E4 483 mm (19 in) 630 mm (24.8 in) 177.8 mm (7 in) 46 kg (101.41 lb) with drives
Avid NEXIS | E5,
Avid NEXIS | E5 NL
483 mm (19 in) 933 mm (36.75 in) 220 mm (8.65 in) 128 kg (282 lb) with drives
System Director
Appliance
Avid NEXIS | E2,
Avid NEXIS | E2 SSD,
Avid NEXIS | PRO Avid NEXIS | E4
Avid NEXIS | E5,
Avid NEXIS | E5 NL
Power Supplies Dual 764W Dual 764W Quad 580W Dual 2200W
Voltage 100 to 240 Vac 100 to 240 Vac 100 to 240 Vac 200 to 240 Vac
Frequency 60/50 Hz 60/50 Hz 60/50 Hz 60/50 Hz
Power Conversion Efficiency
or Power Consumption
>80% @ 100V, >80%
@ 240V (>30% load)
>80% @ 100V, >80% @
240V (>30% load)
>83% @ 100V, >85%
@ 240V (>30% load)
92% @ 240V (50%
load)
Maximum Start-Up Power 764W 764W 1160W 2200W
BTU/Hr 2607 2607 3958 7507
Average Load Power 200W
a
a. Estimated
253W 512W Not measured
BTU/Hr 683
a
863 1747 Not measured
