10
lever overhaul
11
Insert the piston/bladder assembly into the lever body with the
keyed section of the piston retainer oriented toward the opening in
the lever body.
Use the snap ring pliers to push the piston/bladder assembly into
the lever body, and secure the snap ring in its groove. Orient the
snap ring eyelets opposite the opening in the lever body.
You can also use a 10 mm deep socket against the snap ring to push
the piston/bladder/snap ring assembly into the lever body.
If you push the snap ring past its groove, you can use the
2 mm hex in the vise to push on the assembly from inside the fluid
flow port, which will seat the snap ring into the groove.
