12
lever overhaul
13
Use the angled tip of a pick to lift and fasten the eyelet of the lever
return spring onto the spring anchor tab on the snap ring.
14
Use a T10 TORX® wrench to install the pivot bolts into both sides of
the lever. Use a torque wrench with a T10 TORX bit socket to
tighten the pivot bolts to 1.1-1.2 N·m (10-11 in-lb).
T10 1.1-1.2 N·m (10-11 in-lb)
