23
hose length adjustment
6
Apply Avid DOT Grease to the threads of a new hose barb, the
compression fitting outer surfaces and compression nut threads.
While holding the hose firmly, use a T10 TORX® to thread the hose
barb into the end of the hose until it is flush.
Slide a new compression fitting over the end of the hose with the
new hose barb.
7
Push the hose firmly into the lever until it stops.
While holding the hose in place, slide the compression fitting and
compression nut up to the lever or hose stop.
