24
hose length adjustment
8
For models with a compression nut and a hex hose stop: While
continuing to push the hose into the hose stop, use an 11 mm open
end wrench to hold the hose stop in place and use an 8 mm flare
nut wrench to tighten the compression nut to the proper torque.
For models with a compression nut only: While continuing to
push the hose into the lever body, use an 8 mm flare nut wrench to
tighten the compression nut to the proper torque.
· If your compression fitting is alloy, tighten to 5 N·m (47 in-lb).
· If your compression fitting is steel, tighten to 7.8 N·m (70 in-lb)
9
Slide the boot back into place.
After completing the hose length adjustment, bleed the brakes for optimal performance. Click here for detailed brake bleed
instructions
