Installation Steps
Complete the following sections to install the camera.
Required Tools and Materials
The following tools are required to complete the installation but are not included in the package:
l No. 2 Phillips screwdriver — for attaching camera to an electrical box or mounting surface.
Camera Package Contents
Ensure the package contains the following:
l Avigilon H4 Mini Dome Camera (H4M-D), the "camera".
l Surface mounting template sticker
l 2 screws and anchors for solid walls
l Surface mount adapter
l Surface mount bezel
Using the Surface Mount Adapter
The camera is provided with a surface mount adapter that can be mounted to a wall or ceiling.
If the camera needs to be installed in a different way, use one of the other mounting adapter options and refer to
their installation manuals for more information.
l Low-profile in-ceiling mounting adapter
l Gray (H4M-MT-DCIL1)
l Black (H4M-MT-DCIL1-BL)
Perform the following steps if the required cables are coming from inside the mounting surface and the camera
will be mounted immediately over the cable hole. Use this procedure on surfaces that can be easily drilled into,
and when the cables should be kept out of sight.
Installation Steps 10
