Specifications
Camera
Lens 2.8mm, F1.2, IR Corrected
HFOV(Angle of View)
1.3 MP: (5:4) 74°; (16:9) 110°
2.0 MP: (5:4) 74°; (16:9) 110°
3.0 MP: (5:4) 94°; (16:9) 100°, (4:3) 100°
Network
Network 100Base-TX
Cabling Type CAT5
Connector RJ-45
ONVIF® ONVIF compliant with version 1.02, 2.00, Profile S (www.onvif.org)
Security
Password protection, HTTPS encryption, digest authentication, WS authentication, user
access log, 802.1x port based authentication
Protocols
IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP,
Zeroconf, ARP
Streaming Protocols
RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,
RTP/RTSP/HTTPS/TCP, HTTP
Device Management
Protocols
SNMP v2c
SNMP v3
Mechanical
Dimensions
L x W x H
Surface Mount: 73 mm x 73 mm x 52 mm (2.9" x 2.9" x 2.0")
In-ceiling Mount: 89 mm x 89 mm x 39 mm (3.5" x 3.5" x 1.5")
Max. Ceiling
Thickness
In-ceiling Mount: 25 mm (1")
Camera Weight with
Surface Mounting
Bracket
H4M-D1 - 118 g (0.26 lbs)
Camera Weight with
In-ceiling Mounting
Bracket
H4M-D1 - 152 g (0.34 lbs)
Body Polycarbonate and aluminum
Housing Polycarbonate
Finish Cool grey, black
Adjustment Range 360° pan, -5° to 75° tilt, ±115° azimuth
Electrical
Power Consumption 4W
Power Source PoE: IEEE802.3af Class 2 compliant
RTC Backup Battery 3V manganese lithium
Specifications 20
