4
Albatross
Step 3: Slide into each side of the wing center section one of the
aluminum wing joiners. Ensure these are the correct way up, there is
a very slight dihedral angle which should be to the top.
Step 4: Join the connectors for the aileron servo and the wing tip
lights.
