5
7. Install the vertical stabilizer spigots into the corresponding
slots in the rear of the fuselage assembly.
8. Ensure the vertical stabilizer is fully seated into the slots in
the fuselage assembly.
9. Use the supplied 3mm x 20mm, and 3mm x 25mm screws to lock the
vertical stabilizer to the fuselage assembly. Please note: The longer
3mm x 25mm screw should be installed at the front, just behind the
cargo bay door as shown above..
3mm x 25mm
3mm x 20mm
L
