Avios C-130V2 - Page 8

11. Slide through the fuselage the carbon fiber main wing spar.
12. Get the wings ready to slide onto the main wing spar.
6
10. Install the supplied rudder control horn and pushrod as shown
in the picture above.
Please note: The Z link goes to the servo horn, and the ball link
to the rudder horn.
