13. Slide both wings onto the main wing spar.
14. Push both wings up against
the fuselage wing roots, make
sure the electrical connectors
on the wings line up and plug
in correctly.
15. Insert the 4 off 3mm x 10mm
screws into the fuselage wing
roots as shown, if possible, use
a Hex key with ball end to
tighten the screws.
Note: Be careful not to make any
dents in the fuselage when
tightening the screws.
3mm x10mm
7
