This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
This device contains:
FCC ID: G9B-305015
IC: 4680A-305015
CAUTION: Changes or modications not expressly approved by Avire Ltd could void the user’s authority to operate the equipment.
+ 3D False Triggers - Doors closing
In the event of a 3D false trigger on door closing, it is possible that this is simply the sensor picking up the movement of
the doors and seeing it as an approaching object. Immunity to door triggers can be increased by adjusting the 3D radar
low distance and 3D radar o distance (see ‘Smart 3D conguration Options’).
Door Immunity 3D Rdr O Distance 3D Rdr Low Distance
Low Immunity -10 -10
Medium Immunity (Default) 0 0
High Immunity +10 +10
It is recommended that in the event of false triggers on door closing that the high immunity values are used.
Alternatively, to increase detection sensitivity on door closing, please use the Low Immunity values shown above (please
note that this will increase the risk of false triggers). Refer to Section 5. (G3851 controller settings) for further detail.
+ Door triggering wider apart
If the doors trigger above 600mm/23.62”, increase the 3D Rdr Low Dist.
+ Door triggering near to close
If the doors are triggering between 420mm/16.54” and 600mm/23.62”, increase the 3D Rdr O distance.
AVIRE Inc
415 Oser Avenue, Suite Q
Hauppauge, NY 11788
USA
T: 631-864-3699
F: 631-864-2631
E: sales.us@avire-global.com
W: www.januselevator.com
W: www.avire-global.com/us
PC+ RS: PC 20/02/19:V01 (GB)
