AVL DITEST VAS 6910 User Manual

Scope of delivery
VAS 6910 Unpacking Instructions, Start-up, Brief instructions V9.00 10/17 All rights reserved.
447 232 00 00
2-2
2.2 Deliverable Accessories
7.
6910/10
6910/10-1
6910/10-2
6910/10-3
6910/10-4
6910/10-5
6910/10-6
Basic cable set
Module adaption 1: (e-up!)
1. Cable for plus and minus,
loose cable clips
2. Cable for connecting 4 diff.
analog signal connectors
BO7852
BV8190
BV8191
BV8140
BV8141
BV8142
BV8143
ASE 447 240 00 000
ASE 447 246 00 000
ASE 447 247 00 000
ASE 447 248 00 000
ASE 447 249 00 000
ASE 447 250 00 000
ASE 447 251 00 000
8.
6910/11
6910/11-1
6910/11-2
Extension cable set
Module adaption A: (e-Golf)
1. Slave simulation
2. Slave analog measurement
For VOLKSWAGEN e-Golf
both cable sets VAS 6910/11
and VAS 6910/12A are
necessary!
BO7853
BV8145
BV8146
ASE 447 241 00 000
ASE 447 257 00 000
ASE 447 258 00 000
9.
6910/12A
6910/12A-1
6910/12A-2
6910/12A-3
Basic cable set
Module adaption 2:
(PHEV)
1. Cable for plus and minus,
loose cable clips for use
with PHEV module and
AUDI A3-e-tron
2. CAN Cable for connecting
the module controller to the
VAS6910
BO7854
BV8188
BV8189
BV8265
ASE 447 242 01 000
ASE 447 252 00 000
ASE 447 253 00 000
ASE 447 254 00 000
11.
6161/1
2D-Barcodescanner USB
connector
Delivered by Volkswagen AG
ASE 447 043 00 000

AVL DITEST VAS 6910 Specifications

General

Brand	AVL DITEST
Model	VAS 6910
Category	Service Equipment
Language	English
