1. BRIEF INTRODUCTION
1.1. Overview
SE1117 is a HD audio and video encoder which can encode and compress SDI video
and audio source into IP stream, and then transmit it to streaming media server via
network IP address to live broadcast on platforms like Facebook, YouTube, Ustream,
Twitch, Wowza etc.
1.2. Main Features
⚫ 1×SDI input, 1×SDI loop out, 1×Analog audio input
⚫ Supports H.265/ H.264 stream encode protocol, up to 1080p60hz
⚫ Dual-stream (main stream and sub stream)
⚫ RTSP, RTP, RTMPS, RTMP, HTTP, UDP, SRT, unicast and multicast
⚫ Video and audio streaming or single audio streaming
⚫ Image and text overlay
⚫ Mirror image & upside-down image
⚫ Live stream with no need for connecting a computer
1.3. Interfaces
1
LAN Port for Streaming
2
AUDIO Input
3
SDI Input
4
LED Indicator/ RESET hole (Long press 5s)
5
SDI Loopout
6
DC 12V In
