2. SPECIFICATIONS
CONNECTIONS
Video
Input: SDI Type A ×1; Loop Out: SDI Type A ×1
Analog Audio
3.5mm line in ×1
Network
RJ-45×1(100/1000Mbps self-adaptive Ethernet)
STANDARDS
SDI In Format Support
1080p 60/59.94/50/30/29.97/25/24/23.98/23.976,
1080i 50/59.94/60,
720p 60/59.94/50/30/29.97/25/24/23.98,
576i 50, 576p 50, 480p 59.94/60, 480i 59.94/60
Video Coding
H.265/ H.264
Video Bitrate
16Kbps ~ 12MKbps
Audio Coding
ACC/ MP3/ MP2/ G711
Audio Bitrate
24Kbps ~ 320Kbps
Encoding Resolution
1920×1080, 1680×1056, 1280×720, 1024×576, 960×540,
850×480, 720×576, 720×540, 720×480, 720×404,
720×400, 704×576, 640×480, 640×360
Encoding Frame Rate
5-60fps
SYSTEMS
Network Protocols
HTTP, RTSP, RTMP, RTP, UDP, Multicast, Unicast, SRT
Configuration
Management
Web configuration, Remote upgrade
OTHERS
Consumption
5W
Temperature
Working temp: -10℃~60℃, Storage temp: -20℃~70℃
Dimension (LWD)
104×75.5×24.5mm
Weight
Net weight: 310g, Gross weight: 690g
Accessories
12V 2A power supply; Mounting bracket for optional
3. OPERATIONS GUIDE
3.1. Network Configuration and Login
Connect the encoder to network via a network cable. The default IP address of the encoder
is 192.168.1.168. The encoder can auto obtain a new IP address when it is using DHCP
on the network,
Or disable DHCP and configure the encoder and computer’s network in the same network
segment. The default IP address as below.
IP Address: 192.168.1.168
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.1.1
Visit encoder’s IP address 192.168.1.168 through an Internet browser to login the WEB
