Getting Started with ZUBoard 1CG
The Avnet ZUBoard 1CG enables hardware and software developers to explore the capabilities
of the Zynq™ UltraScale+ ZU1. Designers can create or evaluate designs for both the Zynq
Processor Subsystem (PS) and the Programmable Logic (PL) fabric.
A ZUBoard 1CG image in its expected out-of-box configuration is shown below along with the
locations of several key components.
Figure 1 – ZUBoard 1CG
This Getting Started Guide will outline the steps to setup the ZUBoard 1CG hardware. It
documents the procedure to run a PetaLinux design running on the ARM® Cortex™-A9
MPCore™ Processing System (PS).
What’s Inside the Box?
• ZUBoard 1CG development board
• Quick Start Instruction card
Optional add-on items:
• High Speed Expansion Module
o Display Port, Dual Cam, M.2
• Ethernet Cable
• MikroE Click Board
