What’s on the Web?
ZUBoard 1CG is a development kit, with materials being made available through the Avnet
product page, element 14 and Hackster.io community websites.
• http://avnet.me/zuboard-1cg
• http://avnet.me/zuboard-blog
• Hackster.io - The community dedicated to learning hardware.
Official Documentation:
• Getting started guide
• Hardware user guide
• Schematics
• Bill of materials
• Mechanical drawing
• 3D Model
• Board definition files for Vivado integration
• Programmable logic (PL) master user constraints
Tutorials and Reference Designs:
• Introduction to Zynq Design Tutorials
• PetaLinux BSP
• Introduction to Accelerated Edge AI
Trainings and Videos:
• Introduction to ZUBoard 1CG
• Technical Training Course
Available through Avnet FAE:
• Altium source database for schematic and layout
ZUBoard 1CG Basic Setup and Operation
The functionality of the ZUBoard 1CG is determined by the application booted from the non-
volatile memory – by default that is the QSPI. This Getting Started Guide allows system
developers to exercise and demonstrate multiple circuits through FreeRTOS, including:
• RGB LEDs (2)
• Slide Switch (4)
• Red LEDs (4)
• Pressure Sensor
• Temperature Sensor
In addition to the items included in the kit, you will also need the following to complete the
exercises in this tutorial.
