CATEGORY VALUE
Connector 8-pin modular (RJ45)
USB Port
Number 4
Protocol USB 2.0
Power Specifications
Connectors
AutoView 2108/3108: 1 IEC C14
AutoView 2216/3216: 2 IEC C14
Type Internal
Power 18W
Heat Dissipation 47 BTU/hr
AC Input Range 100 - 240 VAC
AC Frequency 50/60 Hz auto-sensing
AC Input Current Rating 0.6A
AC Input Power (Maximum) 20 W
Ambient Atmospheric Condition Ratings
Temperature
Operating: 32 to 122 degrees Fahrenheit (0 to 50 degrees Celsius).
Non-operating: -4 to 158 degrees Fahrenheit (-20 to 70 degrees Celsius)
Humidity
Operating: 20% to 80% relative humidity (RH), non-condensing.
Non-operating: 5% to 95% relative humidity (RH), 38.7 degrees Celsius maximum wet bulb
temperature
Safety and EMC Approvals
Safety and EMC certifications for this product are obtained under one or more of the following
designations: CMN (Certification Model Number), MPN (Manufacturer’s Part Number) or Sales
Level Model designation. The designation that is referenced in the EMC and/or safety reports and
certificates are printed on the label applied to this product.
Vertiv | Avocent® AutoView™ 2108/2216/3108/3216 Switch Installer/User Guide | 60
