Avol itrio - LAN model

Product Specication
17
English
■
Specication
Video Compression
System Latency
Digital Video IN/OUT Interface
Analog Video Input Interface
Analog Video Output Interface
Input Video Ports
Output Video Ports
Video Resolutions (partial list)
Digital Audio IN/OUT Interface
Analog Audio IN/OUT Interface
Analog Audio Transmission
Input Audio Ports
Output Audio Ports
Radio Power
Modulation
Frequencies Supported
Bandwidth
Antenna
Security
WPS
Ethernet LAN
IR in Transmitter
IR in Receiver
Power Supply
Dimensions (mm)
Weight (g)
Color
Operating Temperature
H.264 Baseline Prole Level 4.2
Less than 30 ms delay between Transmitter and Receiver
HDMI-v1.3 compliant, Up to 24 bit RGB or YUV (4:2:2)
RGB Video with D-Sub, Component Video Input, Composite Video Broadcast Signals (CVBS)
YPbPr Component, Composite Video Broadcast Signals (CVBS)
2 x HDMI, 1 x RGB Analog with D-Sub, 1 x CVBS with COMPOSITE
1 x HDMI, 1 x YPbPr RCA, 1 x CVBS with COMPOSITE
480i/p, 720p, 1080i and 1080p (24fps/30fps/60fps)
2 Ch Linear PCM, DTS 5.1 Ch., AC3 5.1 Ch.
Mini stereo headphone jacks
48 kHz sampling with 16bits resolution
2 x HDMI, 1 x Mini Stereo Headphone jack
1 x HDMI, 1 x Mini Stereo Headphone jack x CVBS with COMPOSITE
63mW (+18dBm)
IEEE 802.11n: OFDM
5.15 ~ 5.25 GHz
40 MHz
2T x 2R, 2 internal antenna
802.1x, 802.11i, WPA2, WPA and WEP 64/128 TKIP AES
Wireless Protected Setup for easy set up and security conguration
10/100 BASE-TX
12V/2.0A DC (US/EU standards, CE/FCC/UL certied)
28(W) x 195(H) x 103(D)
Transmitter : 270g , Receiver : 270g
White/Black
Operating from 0°C ~ 40°C
IR Receiver (front side) for itrio's IR Remote Controller
IR Flasher (rear side) for others' IR Remote Controller Blasting
IR Receiver (front side) for itrio's IR Remote Controller and
optional IR Extensive Receiver (rear side)
