MOUNTING AND INSTALLATION
This chapter describes the steps you have to perform to mount and install the Product in a correct and safe
manner.
These steps are subdivided into the following groups, each of which is described in a separate section:
1. Mounting on Wall or Ceiling
2. Connecting the Components to the Camera
3. Connecting a Controller to a Camera
4. Connecting the camera to a local network
Take the following precautions to prevent the Product from falling down which may cause injuries:
• Set up this Product on a hard, stable surface, or mount it to a wall or ceiling.
• ONLY use an Avonic mount for mounting to a wall or ceiling.
• Ensure the mounting construction is capable of supporting four times the weight of the Product. (See
'General Specifications > Weight product’ in the Product Datasheet for the exact weight.)
• Use a safety loop or drop protection that prevents the Product from falling if the mounting construction
fails.
• During mounting and installation, NEVER install a Product above a person.
• Check the installation at least once a year. An improper mounting could cause the unit to fall off,
resulting in personal injury.
Mounting on Wall or Ceiling
The following accessories (AV-MT300) are separately available if the client wants to mount the camera to the wall
or ceiling. Contact your Avonic reseller or local distributor for purchasing details.
Wall and Ceiling mount (AV-MT300)
SKU white: AV-MT300-W
SKU black: AV-MT300-B
Visit www.avonic.com to download instructions for mounting the camera to the wall or ceiling using the
accessory AV-MT300.
14
