AUDIO
Connect first an audio cable with XLR connectors to the 5 pins Phoenix connector and connect the cable
to the camera. See Balanced Audio Connection on page 15
Figure 15: WebGUI > Audio
Make your settings as follows:
1. Enable (checked) or disable (blank) embedding of audio input (camera rear).
2. The encoding type: only AAC.
3. The sample rate: only 48000.
4. Set the sample bits always to 16.
5. Select the Bitrate: 32, 48. 64, 96 or 128 Kbps.
6. Select the Channel: Mono or Stereo.
7. Set the Input Volume: 1 ~ 10.
8. Set the Audio Delay (ms): 0 ~ 200.
9. Click SAVE to apply your settings. A small confirmation dialogue appears in the bottom right corner.
Make sure to enable audio and to click at the audio button on the bottom of the "Preview page" of the
WebGUI.
24
