APPENDIX E - DATASHEET (SPECIFICATIONS)
SPECIFICATIONS
Camera Input / Output Interface
HDMI output HDMI 2.0 up to 4K60
SDI output 3G-SDI, 1080p60 max.
Video Systems HDMI 2160p60, 2160p59, 2160p50, 2160p30,
2160p25, 1080p60,1080p59, 1080p50, 1080i60,
1080i59, 1080i50, 1080p30, 1080p29, 1080p25,
720p60,720p59, 720p50
USB Output USB2.0 Type B, 2160p30 max.
Network interface RJ45 1 Gb.Video Systems SDI 1080p60, 1080p59, 1080p50, 1080i60, 1080i59,
1080i50, 1080p30, 1080p29, 1080p25, 720p60,
720p59, 720p50
Serial interface RS232 mini DIN-8, RS485 2-pin phoenix
Sensor Sony 1/1.8”,8.42MP, 16:9 High SNR CMOS Sensor
Shutter Auto/ Manual 1/60th ~ 1/10000th
General Specifications
Scanning mode Progressive/ Interlace Input Voltage 12V
Zoom/Aperture/Focal lenght 30x zoom*/ F1.6 ~ F11/ 7mm ~ 172mm (+/-5%) PoE PoE 802.3AT (PoE+) at 18 watt
Minimal Illumination 0.05LUX @F1.6 Power consumption 18W
Power supply 12V2AWhite Balance Auto, Manual, One Push, Manual 2400 ~ 7100K
in 100K steps
Power connector EIAJ-4 - Philmore 255 plug
Backlight Compensation supported Operating temperature -5°C ~ 35°C
Digital Noise Reduction supported Storage temperature -20°C ~ 60°C
Signal Noise Ratio >50 dB Operating humidity 20% ~ 95% non-condensing
Horizontal FOV 59.2° - 2.5°
Vertical FOV 34.6° - 1.4°
Bottom fastening screw thread 1/4" 20 UNC
Horizontal rotation +/- 170° Color Black, White
Vertical rotation 120° (30° down, 90° up) 300 x 235 x 300mm
Pan speed range 0.15° ~ 120° p/sec
Dimensions product wxhxd
Tilt speed range 0.15° ~ 70° p/sec Weight product 2.5 kg
H&V image flip supported Dimensions box 30 x 30 x 24 cm
Number of presets 255 with 0.1° accuracy Weight box 3.4 kg
Control over IP Visca over IP, HTTP API Included
Control over Serial Visca, Pelco
Control over IR IR remote control
power adapter, remote control, RS232
cable, RS485 2-way Phoenix connector,
Balanced Audio, Line-In 5-way Phoenix
connector
IP Features Versions
Video coding standard H.265 / H.264 / MJPEG Black CM93-IP-B • CM93-NDI-B
H.265 Profiles main White CM93-IP-W • CM93-NDI-W
H.264 Profiles base, main, high
Main stream resolution 1920x1080/ 1280x720/ 3840x2160
CM93-NDI Only
Main stream max framerate 60fps NDI standard NDI
®
|HX
Main stream bitrate 64 ~ 81920 Kbps
Sub stream resolution 1920x1080/ 720x480/ 640x480/ 640x360/ 320x240
Sub stream max framerate 30fps max
Sub stream bitrate 64 ~ 5120 Kbps
Video bitrate type CBR, VBR
Supported protocols RTSP, RTMP, ONVIF, SRT, Multicast, Unicast
Audio standard AAC
Audio bitrate 32, 64, 96, 128 Kbps
Audio sample rate 48Khz
Audio line in balanced audio by 5-way Phoenix connector
*Avonic’s Optimal Zoom
89
