Avonic CM93-IP User Manual

Video OSD
OSD Offsetx pos Title: {"SetEnv":{"VideoOsd":[{"stTitle":
{"nXPos":9200},"nChannel":0}]}}
nXPos [0, 10000]
Time: {"SetEnv":{"VideoOsd":[{"stTime":
{"nYPos":1200},"nChannel":0}]}}
OSD Offsety pos
Title: {"SetEnv":{"VideoOsd":[{"stTitle":
{"nYPos":1200},"nChannel":0}]}}
nYPos [0, 10000]
OSD Font Size
Get OSD font size parameters
Code {"GetEnv":{"TTFFontSize":{"nChannel":-1}}}
Set video parameters
Code {"SetEnv":{"TTFFontSize":{"nFontSize":[48,48],"bAutoSize":1}}}
Function Code Command Setting
bAutoSize 0: off,1: on
nFontSize [8,200]
Output Format
(Video) Output Format
Get video out parameters
Code {"GetEnv":{"VideoOut":{"nChannel":-1}}}
Set video out parameters
Code {"SetEnv":{"VideoOut":
{"nNetMode":2,"emVoutSdiFormat":10,"nHdmiMode":0,"nHdrMode":0,"emVoutHdmiFormat":10,"byFormaHdmiList":
[50,52,49,47,51,48,10,20,9,8,21,7,4,22,3,6,23,5],"byFormaSdiList":[10,20,9,8,21,7,4,22,3,6,23,5]}}}
Function Code Command Setting
nNetMode:
default value 2, do not modify it
– HD output
– HD output + SD network
– SD output + HD network
Command
emVoutHdmiFormat:
Setting video out format.
emVoutSdiFormat:
Setting SDI video out
format.
Setting Result Setting
50: 4K60
52: 4KP59
49: 4K50
47: 4K30
51: 4KP29
48: 4KP25
10: 1080P60 Same as Hdmi
20: 1080P59 Same as Hdmi
9: 1080P50 Same as Hdmi
8: 1080I60 Same as Hdmi
21: 1080I59 Same as Hdmi
83
