AVPro Edge AC-EX70-UHD-KIT - R S - 2 3 2 C O N F I G U R a T I O

13
RS-232 Conguration
For extending RS-232 communication over the Category
cable. For these to pass a signal, both the Transmitter
and Receiver need to have the Dip Switch set to Normal
Mode, not RS-232 Program.
Default out of the box is MODE NORM (Normal Mode).
RS232 PROG (Program mode for Firmware updating).
